KEY FEATURES
• 5- band 850/900/1800/1900/2100 MHz
• Wireless bearers
  • HSDPA/UMTS (WCDMA/FDD) 2100 MHz
   HSDPA: up to 3.6Mbps downlink,384Kbps uplink.
   UMTS: up to 384Kbps downlink, 384Kbps uplink.
• EDGE (E-GPRS) multislot class 10 and
up to 236.8Kbps downlink, 118Kbps uplink.
• GPRS multislot class 10
• SMS, text/data messaging
• 1 port Ethernet 10/100 Mbps.
• USB port for future use.

 TECHNICAL DETAILS
• RF power (max.)
• Class 4 2W (900 MHz) GSM
• Class 3 0.25W (2100 MHz) UMTS
• Class E2 0.5W EDGE 900.
• Class E2 0.4W EDGE 1800
• Class 1 1W GSM 1800
• Built-in NAT for multiple PC to share.
• Built –in Firewall for protection.
• Support VPN pass through, PPTP, L2TP, IPSec.

INTERFACES
• SIM card interface (3V/1.8V)
• Power supply
• External SMA antenna interface

Embedded system
• Linux

Others
• Size 14cm x 3cm x 11cm
• Weight 0.5 kg
