6 Band LTE: 800/850/900/1500/1700/1800/2100 MHz, FDD-Band  (bands 1, 3, 5, 7, 8, 20)
4 Band UMTS (WCDMA): 850/900/1900/2100 MHz, FDD-Band
Quad Band GSM/GPRS/EDGE:850/ 900/1800/1900 MHz

Speed:
LTE: DL:  Cat.4 max. 150 Mbps, UL: max. 50 Mbps, 2x2 DL MIMO
HSPA+ : DL Cat.24 / UL Cat. 6, Dual Carrier
DL: max. 42 Mbps, UL: max. 5.7 Mbps
UMTS: DL: max. 384 kbps, UL: max. 384 kbps
EDGE: Class 12 data rates DL: max. 237 kbps, UL: max. 237 kbps
GPRS: Class 12 data rates DL: max. 85.6 kbps, UL: max. 85.6 kbps

WiFi
802.11b/g/n 2.4GHz，2T2R，up to 300 Mbps.

INTERFACES
• 4 10/100Mbps LAN port，Auto MDI/MDIX
• 1 10/100/1000Mbps Gbps WAN port, Auto MDI/MDIX
• 1 10/100/1000Mbps Gbps LAN port Auto MDI/MDIX
• 1 SIM card interface (3V/1.8V)
• 1 MicroSD card interface
• Power supply
• External 2 SMA antenna interface for WiFi 2T2R
 External 2 SMA antenna interface for LTE MIMO.
• 1 TTL console port on board

Button:
WPS
System Reset

LED
Power, 2.4GHz wifi status, 4G status, Giga WAN, Giga LAN
4 10/100 LAN ports, Link/Act,WPS

Embedded system
• Linux:. Router can be shared by 250 user at the same time.
Supports OpenWRT，DD-WRT Ralink SDK Linux
Protocol: TCP, FTP, PPTP, HTTP,HTTPS, TFTP, DHCP, NAT, IPSec Pass through, ICMP, IGMP, RIPv2, RIP, OSPF, SNMP, RMON, QoS.
Optional: VPN client or gateway, IPSec client.

Others
• Size 18.8cm x 3cm x 11.4cm
• Weight 0.5 kg
• Operating temperatures
• Normal operating conditions -20...+55 °C
