KEY FEATURES
128T-C1J1 for Japan
4G only: B1(2100), B3(1800), B8(900)
B18(800) B19(800), B26(850)
128T-C1AU for Australia
4G only: B3(1800), B5(850), B8(900), B28(700)
128T-C1WW world wide

4G: B1(2100), B2(1900), B3(1800), B4(AWS1700), B5(850), B8(900), B12(700), B13(700), B18(800), B19(800), B20(800), B26(850), B28(700), B39(1900)
3G: B2(1900),B3(1800),B5(850),B8(900)
Speed
LTE Category M1
Uplink up to 375 kbps,Downlink up to 300 kbps
LTE Category NB1
Uplink up to 20 kbps (single-tone), 250 kbps      (multi-tone) Downlink up to 250 kbps
Functions:
•SMS
•IPv4/IPv6 stack with TCP and UDP protocol
•SSL
•Optional embedded GNSS (GPS, GLONASS, Beidou, Galileo)
TECHNICAL DETAILS
• Power consumption (estimates)
• LTE Data call NBIoT 50mA single tone.
 Cat.M1 112mA Channel BW 10MHz RB=1 0dBm
 Switch off/PSM mode: 0.008mA
• Supply voltage nominal 5V to USB port
• Supply voltage nominal 5V~32V to RS232 port
INTERFACES
• Standard DB9 RS232 serial through
 Molex Microfit 8 pins connector
• Standard Micro USB interface
SIM card interface (3V/1.8V)
• Power supply
External antenna SMA female interface
• Dual color LED for power and link status.

<strong>Others</strong><br /> • Size 6cm x 5cm x 2.3cm Weight 100 g<br /> • Operating temperatures<br /> • Normal operating conditions -30...+70 °C<br /> • Extreme operating conditions -40...+85 °C<br /> • Storage conditions -40...+85 °C
